Brand Name : Neardi
Model Number : LCB3588
Place of Origin : Shanghai, China
MOQ : 1 piece
Price : Negotiable
Payment Terms : L/C, D/A, D/P, T/T
Supply Ability : 100000/pieces/mon
Delivery Time : 7 days
Packaging Details : 33.5×19×9 cm
SoC : RK3588
Supplier Type : OEM/ODM
CPU : 4*A76+4*A55
GPU : ARM Mali-G610 MC4
NPU : 6 Tops
VPU : 8K60FPS
DDR : LPDDR4/LPDDR4X, 4GB/8GB/16GB
eMMC : eMMC 5.1, 32GB/64GB/128GB
Working temperature : industrial grade: -40℃~+85℃ expand commercial grade:-20℃~ 70℃
PCB Interface : B2B
Embedded : Yes
OS : Android/Ubuntu/Buildroot/Debian
Application : Self-service Terminal, 5G smart terminal, etc,., in car
The LCB3588 core module is a highly capable and compact module, designed around the Rockchip RK3588 chip platform. Measuring just 75mm by 70mm, it connects to the baseboard via two 0.8mm pitch 140-pin board-to-board connectors and four 0.5mm pitch 30-pin FPC connectors, all secured by four M2 screws.
This module follows a modular design philosophy, ensuring that the core functionality is designed to meet the strictest standards. All CPU functional pins are carefully laid out and fully tested, providing users with a reliable foundation for product development. With this module, users can significantly shorten project timelines, reduce development costs, and enhance operational efficiency. Additionally, the inclusion of the FPC connector is optional, allowing for flexibility based on functional requirements. Compared to card edge connectors or connectors with smaller pitches (like 0.5mm), the FPC connector offers superior reliability, making it ideal for industrial and vehicle applications that demand durability under vibration and harsh conditions.
| Function | Description |
| SOC | RK3588 8nm, 4*A76+4*A55 |
| GPU | ARM Mali-G610 MC4; OpenGL ES 1.1/2.0/3.1/3.2; Vulkan 1.1/1.2OpenCL 1.1/1.23/2.0. |
| NPU | 6TOPS, int4/int8/int16/FP16/BF16/TF32 |
| VPU | Decode: H.265/H.264/AV1/VP9/AVS2, 8K60FPSEncode: H.264/H.265, 8K30FPS |
| DDR | LPDDR4/LPDDR4X, 4GB/8GB/16GB |
| eMMC | eMMC 5.1, 32GB/64GB/128GB |
| PMU | RK806 |
Hardware Info
| Video Input Interface | MIPI interface: 2 * MIPI(4 lanes) + 4 * MIPI(2 lanes), totally support 6 cameras input; 3 * MIPI(4 lanes) + 2 * MIPI(2 lanes), totally support 5 cameras input; 4 * MIPI(4 lanes) , totally support 4 cameras input; |
| DVP interface: 8/10/12/16-bit standard DVP interface, up to 150MHz input data; | |
| HDMI RX interface: HDMI 2.0 2160p@60 Hz, Support HDCP2.3 and HDCP1.4; | |
| Video Output Interface | 1 * HDMI2.1 up to 8K@60fps; 1 * HDMI2.0 up to 4K@60fps; 2 * MIPI-DSI up to 4K@60fps; 2 * DP1.4 up to 8K@30fps; 2 * eDP1.3 up to 4K@60Hz; 1 * BT.1120 up to 1080@60fps; |
| Image Signal Processor | 8064*6048@15 dual ISP; 6528*4898@30 dual ISP; 4672*3504@30 single ISP; |
| Video Output Processor | Video Port0 up to 7680*4320@60Hz; Video Port1 up to 4096*4320@60Hz; |

| Wiki Documentation: | http://wiki.neardi.net/docs/welcome |
| GitHub: | https://github.com/neardiGitLab: https://gitlab.com/neardiSDK |
| Repository: | https://gitlab.com/neardi-linux |
| Forum: | https://forum.neardi.com |
| Video Tutorials: | https://www.youtube.com/@neardichannels |

|   |
